AREA LIGHT MAL-04

$0.00

Clear

Additional information

MODEL

MODEL NO SELECTION, MAL0440W27 / 120-277 VOLT / 40 WATT / 5,500LM / 0-10 VOLT DIMMABLE, MAL0470W27 / 120-277 VOLT / 70 WATT / 9,600LM / 0-10 VOLT DIMMABLE, MAL04100W27 / 120-277 VOLT / 100 WATT / 13,800LM / 0-10 VOLT DIMMABLE, MAL04150W27 / 120-277 VOLT / 150 WATT / 20,800LM / 0-10 VOLT DIMMABLE, MAL04200W27 / 120-277 VOLT / 200 WATT / 26,000LM / 0-10 VOLT DIMMABLE, MAL04250W27 / 120-277 VOLT / 250 WATT / 34,500LM / 0-10 VOLT DIMMABLE, MAL04300W27 / 120-277 VOLT / 300 WATT / 41,000LM / 0-10 VOLT DIMMABLE, MAL0445W48 / AC 347-480 VOLT / 150 WATT / 5,500LM / 0-10 VOLT DIMMABLE, MAL0470W48 / AC 347-480 VOLT / 150 WATT / 9,600LM / 0-10 VOLT DIMMABLE, MAL04100W48 / AC 347-480 VOLT / 150 WATT / 13,800LM / 0-10 VOLT DIMMABLE, MAL04150W48 / AC 347-480 VOLT / 150 WATT / 21,300LM / 0-10 VOLT DIMMABLE, MAL04200W48 / AC 347-480 VOLT / 150 WATT / 26,000LM / 0-10 VOLT DIMMABLE, MAL04250W48 / AC 347-480 VOLT / 150 WATT / 34,500LM / 0-10 VOLT DIMMABLE, MAL04300W48 / AC 347-480 VOLT / 150 WATT / 42,000LM / 0-10 VOLT DIMMABLE

COLOR TEMPERATURE ( CCT )

CCT NO SELECTION, 4000K, 5000K

FINISH

FINISH NO SELECTION, D-DARK BRONZE (STOCKING FINISH), B-BLACK ( SPECIAL ORDER), W-WHITE ( SPECIAL ORDER), SG-SILVER GRAY ( SPECIAL ORDER)

MOUNTING OPTIONS

MOUNTING OPTIONS NO SELECTION, SLIP FITTER – SPFD04DA, SQUARE/ROUND POLE MOUNT – SQAL04DA, WALLMOUNT – WMAL01DA, YOKE – YKFD04DA, WMAL04DC – WALL MOUNT OF AL04, WMAL04DB – WALL MOUNT

CONTROL

CONTROL NO SELECTION, TWIST-LOCK PHOTOCELL SET(AC120-277V), TWIST-LOCK PHOTOCELL SET(AC480V)

PHOTOMETRY

PHOTOMETRY NO SELECTION, TYPE III PHOTOMETRY ( DEFAULT), TYPE IV PHOTOMETRY, TYPE V PHOTOMETRY

SURGE PROTECTION

SURGE PROTECTION NO SELECTION, SPD-277P / 120-277 VOLT SURGE PROTECTION, SPD 480P / 347-480 VOLT SURGE PROTECTION

BACKLIGHT GUARDS

BACKLIGHT GUARDS NO SELECTION, SC-AL04-100W-DA / BACKLIGHT CONTROL OF AL04-MEDIUM SIZE, DARK BRONZE, SC-AL04-150W-DA /BACKLIGHT CONTROL OF AL04-LARGE SIZE, DARK BRONZE, SC-AL04-300W-DA / BACKLIGHT CONTROL OF AL04-LARGE SIZE, DARK BRONZE

ACCESSORIES

ACCESSORIES NO SELECTION, SQA-AL04DA / ORIENTATION CHANGING BRACKET FOR MAL04-SQ MOUNT

AREA LIGHT AMAL04
